Meraki Part Number: Z4C-HW is a Meraki Z4 Network Security/Firewall Appliance
The Cisco Meraki Z4C teleworker gateway is a high-performance enterprise solution that functions as a firewall, VPN gateway, and router. It features WiFi 6 for wireless connectivity, five gigabit Ethernet ports, and a PoE-enabled port for powering VoIP phones or other PoE devices. Designed to extend the capabilities of Meraki’s cloud-managed networking to virtually any location, the Z4C also includes a built-in LTE modem. This enables seamless deployments requiring backup cellular connectivity or placement in remote areas.
Z4C-HW Highlights:
- Develop an efficient and scalable long-term remote work strategy.
- Ensure secure internet access using Cisco AMP, ThreatGrid, and content filtering.
- WAN: 1 GbE connectivity, integrated Cat 12 LTE modem.
- LAN: 4 GbE ports (including one PoE-enabled port).
- Wi-Fi: Dual-band 2x2 Wi-Fi 6 for improved connectivity.
- Firewall throughput: 500 Mbps.
- Site-to-site VPN throughput: 250 Mbps.
Z4C-HW Features
- Managed via Cisco Meraki Dashboard
- Automatic firmware upgrades
- Layer 3 (L3) and Layer 7 (L7) stateful firewall
- Support for 1:1 and 1:Many NAT
- Configurable VLANs with DHCP support
- Static routing capabilities
- Client VPN endpoint
- Meraki AutoVPN and IPSec VPN endpoint
- Custom traffic shaping options
- Historical client usage statistics tracking
- NetFlow support
- Syslog integration
- Remote packet capture tools
- IPv6 support
- 802.1X wired and wireless authentication support
